• get triggered and powered from incoming gates or CV (provided by voltage sequencers or modular systems)

• increase the natural chaotic movement of electricity by removing the stabilizing elements of a constant power source

• facilitate the sound of electronic circuits loading and unloading, powering up and powering down

• attenuate incoming voltage to all four channels, and between channels

• access swing and groove through natural circuit-loading

• deconstruct programmed rhythm sequences to make surprisingly new ideas

• behave as a drum machine (drum brain)

• behave as a textural drone instrument

• dynamically and organically respond to different gate lengths on each channel, due to power loading characteristics of each circuit type

• achieve movement and textural complexity normally associated with modular instruments and feedback patching

• respond differently to an assortment of CV types (LFO, VCO, envelopes)

• treat each unique channel as a “drum voice” or a chaotic “synth voice” (but more likely somewhere in between)

• span touch plates with fingers, when using it as a drone instrument, to change pitch or texture

• attenuate the links between channels to rhythmically vary modulation between them depending upon when each is receiving CV

coming soon

• Do not attempt to power Moon with anything other than a modular synthesizer or voltage sequencer.

• Clean with a lightly damp (water only) cotton cloth. If a deeper clean is needed, you might try a small amount of rubbing alcohol, but not on the knobs.

• Dimensions: 21cm x 15cm x 1.3cm / 8.25” x 5.9” x 0.5”

• Weight:  0.45 kg. / 1 lb.

• Materials: Gold plated PCB (2mm fiberglass) + metal shaft potentiometers with plastic knobs

• CV Inputs: 6 x 3.5mm jacks

• Audio Inputs: 2 x 3.5mm jacks

• Audio Outputs: 6 x 3.5mm jacks

Each voltage sequencer will have different effects on the tonality of the Moon due to differences in power and feature sets.

Strongest recommendations:

• Arturia Beatstep Pro

• Eurorack modular systems

Sequencers/Control voltage sources that work well:

• Ableton Push 3

• Acid Rain Technology Constellation

• ALM Busy Circuits Pamala’s Workout

• Arturia Beatstep Pro & Keystep Pro

• ET Levit8

• Expert Sleepers ES-9 & FH-2

• Five12 Vector Sequencer

• Frap Tools Falistri

• Lorre Mill Double Knot

• Make Noise 0-ctrl

• Making Sound Machines Stolperbeats

• Mannequins Just Friends

• Meng Qi Voltage Memory

• monome teletype + meadowphysics

• Motu Ultralight as CV interface

• MPC One

• Music Thing Turing Machine + Pulses mkii

• Mutable Instruments Marbles & Stages

• OXI One

• Polyend Poly 2

• Qu-Bit Contour

• Schlappi Engineering Angle Grinder

• Sequentix Cirklon w/ CVIO

• Shakmat Four Bricks Rook

• Sixty Four Pixels CV.OCD

• Social Entropy Engine

• Soma Ornament-8

• Soma Pulsar-23

• Squarp Hermod

• Tiptop Audio Trigger Riot

• vpme.de Euclidean Circles v2

• Westlicht Per Former

• WMD Metron

• ⌘various audio rate oscillators

*We continue to post more examples of working/non-working relationships as we get access to more equipment and learn from users. Thank you for all the suggestions so far!

coming soon
